The engine is also extremely compact. It uses SCEM-coated cylinder bores in place of typical cast-iron liners, which narrow the engine. A side-mounted cam chain allows the use of five main-bearing journals instead of six, further narrowing the powerplant. In addition, the engine is shorter than conventional designs, thanks to transmission shafts mounted behind and below the crankshaft. The compact engine allows the GSX-R750 to have a nimble 55.2-inch wheelbase and 24 degrees of rake, which helps it respond to your input with uncanny precision.

       Complementing those impressive chassis dimensions is a healthy dose of advanced technology that allows the GSX-R750 to maintain its composure even during severe cornering or braking. It features a rigid, diamond-type aluminum frame. Fully adjustable inverted forks and a fully adjustable single shock rear suspension system offer extraordinary performance on a variety of tracks. A steering damper is standard. And state-of-the-art dual front disc brakes with six-piston calipers offer world-class stopping ability.

       For 1999, it's your turn to get on a winning streak: the GSX-R750.

GSX-R750
FEATURES

KEY FEATURES

• "Best 750 Sportbike" - Motorcyclist Magazine - Best Streetbikes of 1998
• Compact & lightweight 4-stroke, 4-cylinder, liquid cooled engine with DOHC, 16-valve/TSCC cylinder head.
• Electronic fuel injection system for strong engine performance and quick throttle response. Includes self diagnostic system with LCD readout.
• 3-piece crankcase design minimizes engine length and simplifies transmission service.
• Right-side positioned cam chain reduces crankshaft width and engine weight.
• Lightweight shim-under-bucket valve train has narrow 29 degree included valve angle.
• Suzuki ram-air induction pressurizes the large capacity airbox for optimum fuel/air mixture and high engine performance.
• SCEM (Suzuki Composite Electro-chemical Material) plated cylinders minimize cylinder-block width and improve heat dissipation.
• High efficiency liquid-cooling system with compact liquid-cooled oil cooler.
• Lightweight magnesium valve cover, breather cover, signal generator & starter clutch covers, and sprocket cover.
• Digital-direct ignition system combines an ignition coil in each spark plug cap. System is simple, lightweight and produces hotter spark.
• Convenient hinged fuel tank swings up to allow quick access to airbox, and spark plugs - without removing fuel hoses.
• Smooth-shifting close-ratio 6-speed transmission with lightweight 525 drive chain.
• Stainless steel 4 into 1 exhaust system tuned for strong overall engine performance.
• Lightweight electric speedo and tach. with LCD displays, twin operation tripmeter and odometer.
• Aluminum spar-type frame is extremely strong and lightweight.
• Bridged-type aluminum swingarm with adjustable pivot point on frame (requires optional race kit components - check race regulation requirements for eligibility).
• Fully adjustable 43mm inverted forks with lightweight aluminum internal components.
• Proven link-type rear suspension with fully adjustable piggy-back style shock absorber.
• Powerful 6-piston front brake calipers with large 320mm rotors and 6-way adjustable brake lever.
• Dunlop Sport Max Radial tires mounted on lightweight cast aluminum wheels. Wide 190-size rear tire is mounted on 6" wide rim.
• Wind tunnel tested fairing design with unique tail section that reduces air turbulence and minimizes rear slipstream.
• Optional Accessories:
  • Gel seat
  • Tank cover
  • Soft luggage
  • Work stands
  • Storage cover
